Detecting Overlaps

확인 완료한 버전: 5.6

-

난이도: 중급

In this live training session we will learn how to create a character controller for a 2D platform game which uses custom physics instead of Unity’s built in 2D Physics.

Detecting Overlaps

중급 2D Game Creation

Download the asset package here

PhysicsObject

Code snippet

using System.Collections;
using System.Collections.Generic;
using UnityEngine;

public class PhysicsObject : MonoBehaviour {

    public float minGroundNormalY = .65f;
    public float gravityModifier = 1f;

    protected Vector2 targetVelocity;
    protected bool grounded;
    protected Vector2 groundNormal;
    protected Rigidbody2D rb2d;
    protected Vector2 velocity;
    protected ContactFilter2D contactFilter;
    protected RaycastHit2D[] hitBuffer = new RaycastHit2D[16];
    protected List<RaycastHit2D> hitBufferList = new List<RaycastHit2D> (16);


    protected const float minMoveDistance = 0.001f;
    protected const float shellRadius = 0.01f;

    void OnEnable()
    {
        rb2d = GetComponent<Rigidbody2D> ();
    }

    void Start ()
    {
        contactFilter.useTriggers = false;
        contactFilter.SetLayerMask (Physics2D.GetLayerCollisionMask (gameObject.layer));
        contactFilter.useLayerMask = true;
    }

    void Update ()
    {
        targetVelocity = Vector2.zero;
        ComputeVelocity ();
    }

    protected virtual void ComputeVelocity()
    {

    }

    void FixedUpdate()
    {
        velocity += gravityModifier * Physics2D.gravity * Time.deltaTime;
        velocity.x = targetVelocity.x;

        grounded = false;

        Vector2 deltaPosition = velocity * Time.deltaTime;

        Vector2 moveAlongGround = new Vector2 (groundNormal.y, -groundNormal.x);

        Vector2 move = moveAlongGround * deltaPosition.x;

        Movement (move, false);

        move = Vector2.up * deltaPosition.y;

        Movement (move, true);
    }

    void Movement(Vector2 move, bool yMovement)
    {
        float distance = move.magnitude;

        if (distance > minMoveDistance)
        {
            int count = rb2d.Cast (move, contactFilter, hitBuffer, distance + shellRadius);
            hitBufferList.Clear ();
            for (int i = 0; i < count; i++) {
                hitBufferList.Add (hitBuffer [i]);
            }

            for (int i = 0; i < hitBufferList.Count; i++)
            {
                Vector2 currentNormal = hitBufferList [i].normal;
                if (currentNormal.y > minGroundNormalY)
                {
                    grounded = true;
                    if (yMovement)
                    {
                        groundNormal = currentNormal;
                        currentNormal.x = 0;
                    }
                }

                float projection = Vector2.Dot (velocity, currentNormal);
                if (projection < 0)
                {
                    velocity = velocity - projection * currentNormal;
                }

                float modifiedDistance = hitBufferList [i].distance - shellRadius;
                distance = modifiedDistance < distance ? modifiedDistance : distance;
            }


        }

        rb2d.position = rb2d.position + move.normalized * distance;
    }

}

PlayerPlatformerController

Code snippet

using System.Collections;
using System.Collections.Generic;
using UnityEngine;

public class PlayerPlatformerController : PhysicsObject {

    public float maxSpeed = 7;
    public float jumpTakeOffSpeed = 7;

    private SpriteRenderer spriteRenderer;
    private Animator animator;

    // Use this for initialization
    void Awake ()
    {
        spriteRenderer = GetComponent<SpriteRenderer> ();
        animator = GetComponent<Animator> ();
    }

    protected override void ComputeVelocity()
    {
        Vector2 move = Vector2.zero;

        move.x = Input.GetAxis ("Horizontal");

        if (Input.GetButtonDown ("Jump") && grounded) {
            velocity.y = jumpTakeOffSpeed;
        } else if (Input.GetButtonUp ("Jump"))
        {
            if (velocity.y > 0) {
                velocity.y = velocity.y * 0.5f;
            }
        }

        bool flipSprite = (spriteRenderer.flipX ? (move.x > 0.01f) : (move.x < 0.01f));
        if (flipSprite)
        {
            spriteRenderer.flipX = !spriteRenderer.flipX;
        }

        animator.SetBool ("grounded", grounded);
        animator.SetFloat ("velocityX", Mathf.Abs (velocity.x) / maxSpeed);

        targetVelocity = move * maxSpeed;
    }
}
