Unity Tips and Tricks Grab Bag

Checked with version: 5.2

-

Difficulty: Intermediate

Who doesn't like #unitytips? In this session we will look at a bunch of different tips and tricks that you may not have known about. Topics include how to: Visualizing in the scene view with editor extensions, modularizing assets, and using particles for performance gain. We are literally cramming as much stuff into an hour session as we can, so who knows how much we'll cover! Let's find out! Trainer: Mike Geig

Unity Tips and Tricks Grab Bag

Intermediate Tips

Scripts for the navigation editor extensions

CharacterNavigation

Code snippet

using UnityEngine;

public class CharacterNavigation : MonoBehaviour
{
    public Transform target;

    NavMeshAgent agent;

    void Awake()
    {
        agent = GetComponent<NavMeshAgent>();
    }

    void Update ()
    {
        agent.SetDestination(target.position);
        agent.Stop();
    }
}

CharacterNavigationEditor

Code snippet

using UnityEngine;
using UnityEditor;

[CustomEditor(typeof(CharacterNavigation))]
public class CharacterNavigationEditor : Editor
{
    static bool visualizePath = false;

    public override void OnInspectorGUI()
    {
        DrawDefaultInspector();

        visualizePath = EditorGUILayout.Toggle("Visualize Path", visualizePath);
    }

    [DrawGizmo(GizmoType.Selected | GizmoType.NonSelected)]
    static void DrawLinesForNavAgent(NavMeshAgent agent, GizmoType gizmoType)
    {
        if (!visualizePath || agent.path == null)
            return;

        Gizmos.color = Color.red;
        Vector3[] points = agent.path.corners;
        for (int i = 0; i < points.Length - 1; i++)
        {
            Gizmos.DrawLine(points[i], points[i + 1]);
        }
    }
}

Scripts for the particle optimizations

EmitterScript

Code snippet

using UnityEngine;
using System.Collections;

public class EmitterScript : MonoBehaviour
{
    public float rate = 20f;
    public int maxCoins = 100;
    public GameObject coin;

    Rigidbody2D[] coins;
    int index;
    float amntPerUpdate;

    void Start ()
    {
        coins = new Rigidbody2D[maxCoins];
        for (int i = 0; i < maxCoins; i++)
        {
            coins[i] = (Instantiate(coin) as GameObject).GetComponent<Rigidbody2D>();
            coins[i].gameObject.SetActive(false);
        }

        amntPerUpdate = rate * .02f;
        index = 0;
    }

    void FixedUpdate()
    {
        for (int i = 0; i < amntPerUpdate; i++)
        {
            coins[index].gameObject.SetActive(false);
            coins[index].transform.position = transform.position;
            coins[index].transform.rotation = Quaternion.identity;
            coins[index].gameObject.SetActive(true);

            Vector3 velocity = new Vector3(Random.Range(-2f, 2f), 10f, 0f);
            coins[index].velocity = velocity;

            if (++index >= maxCoins)
                index = 0;
        }
    }
}

ParticleCoinScript

Code snippet

using UnityEngine;

public class ParticleCoinScript : MonoBehaviour
{
    public ParticleSystem coinSystem;
    public Transform playerPosition;
    public float floorHeight = 0f;

    int maxParticles;
    ParticleSystem.Particle[] coins;

    void Start()
    {
        maxParticles = coinSystem.maxParticles;
        coins = new ParticleSystem.Particle[maxParticles];
    }

    void Update()
    {
        coinSystem.GetParticles(coins);

        for (int i = 0; i < coins.Length; i++)
        {
            //Bounce
            if (coins[i].position.y < floorHeight)
            {
                if (coins[i].velocity.y < 0)
                    coins[i].velocity = new Vector3(coins[i].velocity.x, 5, coins[i].velocity.z);
                else
                    coins[i].position = new Vector3(coins[i].position.x, floorHeight, coins[i].position.z);
            }

            //Collect by player
            float distance = Vector3.Distance(coins[i].position, playerPosition.position);
            if (Mathf.Abs(distance) <= 1.5f)
                coins[i].lifetime = 0f;
        }

        coinSystem.SetParticles(coins, maxParticles);
    }
}
